RPC weekly meeting

Thursday 14 Nov 2024, 13:00 → 16:00 Europe/Bucharest

Conference Room

Mariana Petris (National Institute for R&D in Physics and Nuclear Engineering (IFIN-HH), Bucharest)

13:10 → 13:20 Status of the twisted pair signal cable for implementation in M0

• Manual of cable manufacturing, labeling and their mapping
• Status of the manufacturing of the signal cables

Speakers: Florin Gila, George Stoian, Gheorghe Caragheorgheopol, Valerica Aprodu

M0-S1_cabling.pdf

M0_Signal-Cabling-19 sept2024.pdf

13:20 → 13:40 M0 backplane equipment

• gas pipe connection
• HV polarity labeling

Speakers: Andrei Radu, George Stoian, Gheorghe Caragheorgheopol, Valerica Aprodu, Viorel Duta



• realizat distantori pentru manevrarea back panel
• montat conectorii HV
• se vor realiza olivele si stuturile si se vor monta in conectorii de gaz
• se va incepe efectiv activitatea la 17 septembrie pentru pipe-urile de gaz

13:40 → 14:10 discussion about the components for the assembling of M0's chambers

• on-going
  - resistors soldering on HV boards
  - honeycomb plates preparations
  - subcomponents assembling
  - HV connection of MSMGRPC

• needed:
  - Gas distributors for 60 – 56 pieces
  - Gas distributors for 100 – 24 pieces
  - Gas distributors for 200 – 48 pieces
  - Mini-rod for 60 – 136 pieces
  - Mini-rod for 100 – 48 pieces
  - Mini-rod for 200 – 96 pieces
  - Tightening ledges - 72 pieces

Speakers: Andrei Radu, Florin Gila, George Stoian, Valerica Aprodu

Status-of- the-components-for-M0_09.10.2024.pdf

The status of the components for M0_24.10.2024.pdf

dispozitive de manevrare modul M0 - Viorel -> de dat in lucru

placa de test -> de dat in lucru

limitatorii de fixat in pozitie -> de dat in lucru



Andrei R - devic pentru montarea spacer ilor - data viitoare ne prezinta statusul lor

14:10 → 14:20 Design of the CBM-TOF inner zone based on the direct flow MSMGRPCs

• priority -> second M0 module:
  - back panel - arrived
  - mechanical supports - arrived
  - housing box - ordered
  - Connector and electrodes PCBs - arrived
  -HV CAEN connectors - arrived
  - cornier bars ???
  - Al bars for housing box assembling ???
  - electronics supports for M0?

• Number of detectors by type in the CBM-TOF inner zone:

  • MRPC1a ( 60 mm) - 40
  • MRPC1b (100 mm) - 108
  • MRPC1c (200 mm) - 168

-status of the design of the modules of the inner zone - Viorel
- 2 M3 design ready
- back panels - offers, orders?
- 4 M1 design ready
- 2 M2 design in progress
- electronics supports?

Speakers: Andrei Naziru, Laura Radulescu (IFIN-HH), Viorel Duta

14:20 → 14:30 in-beam and in - house tests

• housing box and backplane for in-house and in-beam tests
  - housing box - we have
  - back plane manufacturaed -> need equipped
  - mechanical supports for in house tests - designed
  - mechanical supports for in-beam test ?
  - mecanical supports for FEE for in-beam tests.

nu exista material pt suporti electronica- dl. Duta se ocupa sa aduca oferta

Speakers: Andrei Radu, Florin Gila, George Stoian, Valerica Aprodu

14:30 → 14:50 INVENTOR compatibility check and procurement

• transfer of knowledge status
• status of the procurement - Andrei Naziru

Speakers: Andrei Naziru, Laura Radulescu (IFIN-HH), Viorel Duta

14:50 → 15:10 backup of all files belonging to the design of the CBM-TOF inner zone

• design of the spacers' position - Laura
• any update made from last backup - Laura

Speaker: Mariana Petris (National Institute for R&D in Physics and Nuclear Engineering (IFIN-HH), Bucharest)

15:10 → 15:30 Assembling manual

• chamber assembling -> in progress
• what about module assembling manual? Viorel, Cara, Laura, George, Vali

Speakers: Mariana Petris (National Institute for R&D in Physics and Nuclear Engineering (IFIN-HH), Bucharest), Valerica Aprodu

15:30 → 15:40 Status of the in-kind contract draft

Speakers: Mariana Petris (National Institute for R&D in Physics and Nuclear Engineering (IFIN-HH), Bucharest), Prof. Mihai Petrovici (National Institute for Physics and Nuclear Engineering (IFIN-HH))

CBM-TOF_Inner_Wall_Costs.pdf

15:40 → 16:00 aob
